Robust performanceEquipped with a non-blocking bandwidth of 20 Gbps and a forwarding rate of 14.88 Mpps, the TSW212 ensures efficient data flow and high-speed connectivity for all connected devices.Enhanced securityFeaturing advanced authentication methods including RADIUS and TACACS+, along with DHCP Snooping, the TSW212 provides a secure networking environment by preventing unauthorized access.Versatile connectivityWith 8 RJ-45 ports for 10/100/1000 Base-T connections and 2 SFP slots for 1000Base-X, the TSW212 offers flexible options for linking a wide range of devices and extending network reach.Durable designHoused in an anodized aluminum casing with IP30 protection, the TSW212 is built to withstand harsh industrial environments, ensuring reliable operation in temperatures ranging from -40 °C to 75 °C.Intelligent managementSupport for Teltonika Remote Management System (RMS) alongside SNMP 2 and SNMP 3 protocols enables efficient monitoring and management of network resources, enhancing system reliability.
Спецификации
- ManufacturerTELTONIKA NETWORKS
- Manufacturer Part NoTSW212000000
- Device TypeSwitch - 8 ports - Managed
- Enclosure TypeDIN rail mountable, surface-mountable
- CapacityPacket buffer size: 512 KB
- Routing ProtocolSTP, RSTP, static IPv4 routing, static IPv6 routing
- Remote Management ProtocolSNMP 3, SNMP 2, DHCP, RADIUS
- Authentication MethodRADIUS, TACACS+
- FeaturesAuto-uplink (auto MDI/MDI-X), EtherNet/IP enabled, PROFINET, LLDP support, VLAN support, MRP support, loop protection, DHCP server, DHCP client, port isolation, EEE, port mirroring, DHCPv6 client, PAM, PSK, QoS, DSCP prioritisation, ToS, rate limit, Storm Control, traffic shaping, Teltonika RMS, FOTA, reset button, ground points, anodised aluminium housing
- Compliant StandardsIEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3az
- RAM128 MB DDR3 SDRAM
- Flash Memory16 MB
- Status IndicatorsPower, AUX, Ethernet link/activity, SFP
- Interfaces8 x 10/100/1000 Base-T RJ-45 2 x 1000Base-X SFP
- Width13.2 cm
- Depth12.22 cm
- Height4.42 cm
- Weight615 g
- Min Operating Temperature-40 °C
- Max Operating Temperature75 °C
- Humidity Range Operating10 - 90% (non-condensing)
- Warranty36 months
- EAN4779051841370
- SubtypeGigabit Ethernet
- Ports8 x 10/100/1000 + 2 x SFP
- PerformanceNon-blocking bandwidth: 20 Gbps Forwarding rate: 14.88 Mpps
- MAC Address Table Size8K entries
- Jumbo Frame Support10000 bytes
- Voltage RequiredDC 7 - 57 V
- Miscellaneous / Compliant StandardsIP30, UKCA, RCM, ANRT, FCC, IC, CB, RoHS, REACH, NBTC, EN 55032:2015+A1:2020+A11:2020, EN 55035:2017+A11:2020, EN 61000-3-3:2013+A1:2019+A2:2021, EN 61000-4-2:2009, EN IEC 61000-3-2:2019+A1:2021, EN 61000-4-3:2020, EN 61000-4-4:2012, EN 61000-4-5:2014+A1:2017, EN 61000-4-6:2014, EN IEC 61000-4-11:2020, IEC 61000-4-3:2020, AS/NZS 62368-1:2022, EN IEC 62368-1:2020+A11:2020, IEC 62368-1:2018
- Software IncludedWitchOS
